Products
· Handle small size, light weight, easy to carry;
· Product performance, stability, security, performance, use of confidence;
· Two-way communication, no crystal, interference, drop, shock;
Product Features
· Remote Control Set 6 Single-speed button start button +1 +1 emergency stop button;
· Host power supply design is AC36V, 48V, 220V, 380V, 450V, the voltage to meet different customer requirements;
· Signal indicator and battery level indicator designed separately, more intuitive response remote working status;
· No need to disassemble the remote control can be realized a pair of receiving host multiple functions, simple and easy;
· Control cables with fast connection port design, the user can demand, self-control matching the right cable;
· Rugged aluminum enclosure supporting high-quality protective cover, can effectively seismic, anti-collision;
· Remote Control Protection class IP65, surface anti-oil, anti-dust, corrosion resistance, in full compliance with the factory environment;
Technical indicators
Remote control transmitter
Size: 132.5 * 66 * 34 (mm) Weight: 180g (without batteries)
Control Distance: 200m
Operating frequency: 433MHz
Transmit Power: 10dBm
Receiver sensitivity:-112dBm
Use Antenna: Built-in
Adapt to temperature: -10 ℃ to +75 ℃ (without regard to battery temperature)
Power supply: AAA * 4 Pieces (4 7 batteries)
Shell Material: tpu + abs
Protection: IP65
Remote Receiver
Size: 205 * 134 * 60 (mm) Weight: 500g
Frequency: 433MHz
Frequency spacing: 50KHz
Use Antenna: Built-in transmitter power: 10dBm
Receive sensitivity:-112dBm
Relay: 10A, 250VAC
Operating temperature: -10 ℃ ~ +75 ℃
Optional power: AC 36V, 48V, 220V, 380V, 450V
Power consumption: <3W
Housing protection: IP67
|
|
Remote Control Specifications
|
Receiver Specifications
|
|
Technical Parameters
|
Control Distance: 200m
Operating frequency: 433MHz
Transmit Power: 10dBm
Receiver sensitivity:-112dBm
Use Antenna: Built-in
Adapt to temperature: -10 ℃ to +75 ℃ (without regard to battery temperature)
Power supply: AAA * 4 Pieces (4 on the 7th battery)
Shell Material: tpu + abs
Protection: IP65
|
Frequency spacing: 50KHz
Use Antenna: Built-in
Transmit Power: 10dBm
Receive sensitivity:-112dBm
Relay: 10A, 250VAC
Operating temperature: -10 ℃ ~ +75 ℃
Optional power: AC 36V, 48V, 220V, 380V, 450V
Power consumption: <3W
Housing protection: IP67
|
|
Dimensions
|
Size: 132.5 * 66 * 34 (mm)
Weight: 180g (without batteries)
|
Size: 205 * 134 * 60 (mm)
Weight: 500g
|
|
